SPD Series - 1,500 lbs
The SPD Series 1500 lb. actuator is a heavy-duty device designed for tough industrial applications requiring reliable movement and position holding, with features enhancing its durability and adaptability. The bi-directional spring braking system is a powerful and precise device designed for demanding applications requiring controlled linear motion.
Standard Configurations
Capacity (lbs):
1500
Stroke Length (in):
3, 6, 12, 18, 24, 30, 36
Need Assistance?
Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.
Specifications
Specifications
| SPD Series 1500 lb Product Specifications | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Rated Loads | Stroke Length | Retracted Length | Voltage | Current Draw* | Speed* | Clutch | Duty Cycle* | |||
| # | (lbs) | in | mm | in | mm | vdc | amp | in/s | mm/s | Y/N | % |
| LSPD6415-3 | (1500) 6672 | 3 | 76 | 17.1 | 434 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| LSPD6415-6 | (1500) 6672 | 6 | 152 | 20.1 | 511 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| LSPD6415-12 | (1500) 6672 | 12 | 305 | 26.1 | 663 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| LSPD6415-18 | (1500) 6672 | 18 | 457 | 32.1 | 815 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| LSPD6415-24 | (1500) 6672 | 24 | 610 | 38.1 | 968 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| LSPD6415-30 | (1500) 6672 | 30 | 762 | 50.1 | 1273 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| LSPD6415-36 | (1500) 6672 | 36 | 915 | 56.1 | 1425 | 12 | 27 | 0.43 | 11 | Yes | 27% |
| * At Rated Load | |||||||||||
