CMLA-A Series - 500 Lbs
The CMLA-A Series 500 lb. capacity linear actuator with an IP66S protection rating, sealed bearings, and high-quality lubricants is a robust and versatile device designed for industrial and outdoor applications where it will be exposed to dust and water. Sealed bearings promote a long service life by preventing contaminants from entering. High-quality lubricants provide smooth operation and extended lifespan.
Documents
Need Assistance?
Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.
Specifications
Specifications
CMLA A Series 500 lb Product Specifications |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Capacitor Model | Motor | Max. Dynamic Load | Max. Static Load | Screw | Gear | Motor Power | Amperage | Lifting Speed | Duty Cycle | Capacitor Rating |
| # | Type | (lbs) N | (lbs) N | Type | Ratio | Volts | Amps | (in/s) mm/s | (in/hr) m/hr | mdf |
| SK6405-7-13 | AC | (500) 2200 | (750) 3336 | Trapezoid | 11.5 | 115 | 2.3 | (0.71) 18.0 | (810) 20.6 | 35 |
| SK6405-7-10 | AC | (500) 2200 | (750) 3336 | Trapezoid | 11.5 | 230 | 1.4 | (0.71) 18.0 | (810) 20.6 | 10 |
| SK6405-7-13 | AC | (500) 2200 | (750) 3336 | Ball | 6.5 | 115 | 2.4 | (1.5) 38.1 | (1200) 30.5 | 35 |
| SK6405-7-10 | AC | (500) 2200 | (750) 3336 | Ball | 6.5 | 230 | 1.5 | (1.5) 38.1 | (1200) 30.5 | 10 |
| Notes: 1. The correct capacitor mfd should be used for each model or the cylinder will not perform as rated. 2. Order Hard Start Kit 192036494 for applications where high starting torque is required (low temperature, high starting load) |
||||||||||
