Lineman's Strap Hoist
The Little Mule Lineman's Strap Hoist is high quality and dependable, making it one of the favorites of linemen across the nation. This strap hoist is designed for rugged use with dependability in mind.
Standard Configurations
Documents
Need Assistance?
Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.
Features and Benefits
Designed for safety and dependability
Explore the features of the Little Mule 344C Lineman's Strap Hoist, the preferred hoist of utility industry professionals. Little Mule helps you get the job done and home safe – even in the most hazardous environments.
Watch Video
Features and Benefits
Non-Conductive Handle
Fiberglass handle with polyester webbing provides added non-conductive material when using proper hot line handling techniques. Some models also available with hot stick ring on handle.
Overload Feature
Solid fiberglass handle, with replaceable tips, bends to alert operator of a possible overload.
Hooks and Gate Latches
All hooks swivel 360° and are equipped with latches. Optional hooks with gates can also be added.
Positive Load Holding
Double interlocking pawls assure one pawl is engaged at all times. Dual pawl springs provide unsurpassed reliability.
Safe Design
Thumbscrews used to secure the handle are pegged and cannot be backed out. Competitive units use butterfly nuts which can cause the handle to come loose.
Open Design
The open design allows for easy inspection and cleaning.
Lightweight and Rugged
These hoists are made with cast aluminum frames as well as corrosion-resistant stainless steel springs and frame shafts. Roller shafts are stainless steel plated. All rotating shafts are mounted on bronze bushings for reduced wear.
Easy Load Positioning
Utilizing a double pawl system, this multiple pawl stops for precise load adjustment.
Easy to Operate
Self-storing web drum provides compact operation. Non- conductive winding wheel provided for quick take-up or positioning of slack webbing.
4:1 Design Factor
Meets or exceeds minimum 4:1 design factor and all requirements of ASME/ANSI Standard B-30.21. All units tested at 125% of rated load.
Adjustable Capacity Hoist Option
Double-reeved hook block configuration increases capacity. Easily removable sheave block with a quick disconnect design allows the hoist to be converted for double or single-line use.
Models Available
|
MODEL 250A 1 ton Capacity Standard Hooks & Safety Latches Hook Options:
|
MODEL 300A 1-1/2 ton Capacity Standard Hooks & Safety Latches Hook Options:
|
MODEL 322C 1-1/2 ton Capacity Standard Hooks & Safety Latches Hook Options:
|
MODEL 344C 2 ton Capacity Standard Hooks & Safety Latches Hook Options:
|
MODEL 6000A 3 ton Capacity Standard Hooks & Safety Latches Hook Options:
|
How To Properly Inspect Your Lever Strap Hoist
When using a lever strap hoist, it’s important to inspect it regularly to prevent accidents or product failures. These inspections are broken down into frequent and periodic inspections.
Specifications
Specifications
| Model Number | Capacity | Handle Length | Lift (ft) | Weight (lbs) |
|---|---|---|---|---|
| C04141W | 21.4 | 9 | 11 | |
| C04142W | 22.8 | 9.25 | 11.5 | |
| C04143W | 21.4 | 9 | 11 | |
| C04144W | 22.8 | 9.25 | 11.5 | |
| C04181W | 25.3 | 5 | 25.5 | |
| C04182W | ||||
| C04183W | 25.3 | 5 | 12.5 | |
| C04190W | 21.4 | 9 | 11 | |
| C04191W | 22.8 | 9.25 | 11.5 | |
| C04192W | 21.4 | 9 | 11 | |
| C04193W | 22.8 | 9.25 | 11.5 | |
| C04480WC | 25.8 | 14 | 11.5 | |
| C04481W | 14 | 11.5 | ||
| C04481WC | 24 | 14 | 11.5 | |
| C04482WC | 25.8 | 14 | 11.5 | |
| C04483WC | 27.2 | 14 | 11.5 | |
| C04490WC | 11 | 12.5 | ||
| C04491WC | 33.2 | 11 | 13 | |
| C04492WC | 31.8 | 11 | 12.5 | |
| C04493WC | 33.2 | 11 | 13 |
