SPA Series - 1,500 lbs

The SPA Series 1500 lb. capacity, Acme screw linear actuator with internal, adjustable limit switches and automatic reset thermal overload motor protection is a type of electric linear actuator designed for heavy-duty applications requiring controlled, linear motion with built-in safety features. The automatic reset safeguards the motor from overheating due to excessive load or prolonged operation.

Need Assistance?

Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.

Features & Benefits

  • Versatile Design
    Wide range of capacities and voltages for integration into a variety of applications
  • Durable
    Heavy duty design for long life in tough environments
  • Corrosion resistant housing
  • Precise Positioning
    Precise and repeatable positioning with internal, adjustable limit switches
  • Overload Protection
    Automatic reset thermal overload motor protection
  • Resists Back Driving
    Mechanical braking system to reduce back driving and stopping distance
  • Custom Solutions
    Available with experienced Application Engineering Team

Specifications

Part Number Rated Loads Stroke Length Retracted Length Voltage Current Draw Speed* Limit Switch POT Duty Cycle
# (lbs) N in mm in mm (VAC) Hz Amp in/s mm/s Yes/No Y/N %
SPA6415-3 (1500) 6672 3 76 17.1 434.3 (115) 60 6.5 0.83 21 Yes Yes 17%
SPA6415-6 (1500) 6672 6 152 20.1 510.5 (115) 60 6.5 0.83 21 Yes Yes 17%
SPA6415-12 (1500) 6672 12 305 26.1 662.9 (115) 60 6.5 0.83 21 Yes Yes 17%
SPA6415-18 (1500) 6672 18 457 32.1 815.3 (115) 60 6.5 0.83 21 Yes Yes 17%
SPA6415-24 (1500) 6672 24 610 38.1 967.7 (115) 60 6.5 0.83 21 Yes Yes 17%
SPA6415-30 (1500) 6672 30 762 50.1 1273 (115) 60 6.5 0.83 21 Yes Yes 17%
SPA6415-36 (1500) 6672 36 915 56.1 1425 (115) 60 6.5 0.83 21 Yes Yes 17%
PSPA6415-3 (1500) 6672 3 76 17.1 434.3 (115) 60 6.5 0.83 21 Yes Yes 17%
PSPA6415-6 (1500) 6672 6 152 20.1 510.5 (115) 60 6.5 0.83 21 Yes Yes 17%
PSPA6415-12 (1500) 6672 12 305 26.1 662.9 (115) 60 6.5 0.83 21 Yes Yes 17%
PSPA6415-18 (1500) 6672 18 457 32.1 815.3 (115) 60 6.5 0.83 21 Yes Yes 17%
PSPA6415-24 (1500) 6672 24 610 38.1 967.7 (115) 60 6.5 0.83 21 Yes Yes 17%
PSPA6415-30* (1500) 6672 30 762 50.1 1273 (115) 60 6.5 0.83 21 No Yes 17%
PSPA6415-36* (1500) 6672 36 915 56.1 1425 (115) 60 6.5 0.83 21 No Yes 17%
SPA7415-3 (1500) 6672 3 76 17.1 434.3 (220) 50 2 0.68 17 Yes No 25%
SPA7415-6 (1500) 6672 6 152 20.1 510.5 (220) 50 2 0.68 17 Yes No 25%
SPA7415-12 (1500) 6672 12 305 26.1 662.9 (220) 50 2 0.68 17 Yes No 25%
SPA7415-18 (1500) 6672 18 457 32.1 815.3 (220) 50 2 0.68 17 Yes No 25%
SPA7415-24 (1500) 6672 24 610 38.1 967.7 (220) 50 2 0.68 17 Yes No 25%
SPA7415-30 (1500) 6672 30 762 50.1 1273 (220) 50 2 0.68 17 Yes No 25%
SPA7415-36 (1500) 6672 36 915 56.1 1425 (220) 50 2 0.68 17 Yes No 25%
PSPA7415-3 (1500) 6672 3 76 17.1 434.3 (220) 50 2 0.68 17 Yes Yes 25%
PSPA7415-6 (1500) 6672 6 152 20.1 510.5 (220) 50 2 0.68 17 Yes Yes 25%
PSPA7415-12 (1500) 6672 12 305 26.1 662.9 (220) 50 2 0.68 17 Yes Yes 25%
PSPA7415-18 (1500) 6672 18 457 32.1 815.3 (220) 50 2 0.68 17 Yes Yes 25%
PSPA7415-24 (1500) 6672 24 610 38.1 967.7 (220) 50 2 0.68 17 Yes Yes 25%
PSPA7415-30* (1500) 6672 30 762 50.1 1273 (220) 50 2 0.68 17 No Yes 25%
PSPA7415-36* (1500) 6672 36 915 56.1 1425 (220) 50 2 0.68 17 No Yes 25%
* At Rated Load
